| 設備特性 | |
|---|---|
| 尺寸 | 165 mm L x 76.3 mm W x 12.5 mm D |
| 重量 | 236 克（含標準電池） |
| 顯示螢幕 | 6.0 英寸彩色高清顯示屏(1080 x 2160)；LED 背光；450 Nits；Corning® Gorilla® 玻璃 |
| 電池 | 可拆卸，可充電耐用型鋰離子電池。標準容量3800 mAh，高容量5200 mAh |
| 擴展插槽 | microSD 2TB |
| 網路連接 | TC22: WLAN, WPAN; TC27: WWAN, WLAN, WPAN |
| SIM卡 | 1 Nano SIM and 1 eSIM（僅限TC27） |
| 性能特性 | |
|---|---|
| 處理器(CPU) | Qualcomm® 5430 hex-core, 2.1 GHz |
| 作業系統(OS) | Upgradeable to Android 16 |
| 記憶體 | 6 GB RAM/64 GB UFS Flash; 8 GB RAM/128 GB UFS Flash |
| 用戶環境 | |
|---|---|
| 作業溫度 | -10°C to 50°C |
| 儲存溫度 | -40°C to 70°C |
| 耐用測試 | 在工作溫度範圍內，可承受從5 英尺（1.5 米）高處跌落至混凝土地面的衝擊，符合MIL-STD 810H 標準。可承受從1.6 英尺（0.5 米）滾落300 次的衝擊 |
| 密封 | IP68 and IP65, 根據適用的 IEC 密封規範配備電池 |
| 數據採集 | |
|---|---|
| 掃描 | SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology; SE4710 1D/2D Scan Engine |
| 相機 | 1600 萬像素後置攝像頭；500 萬像素前置攝像頭 |
| 無線通信 | |
|---|---|
| WWAN Radio（僅限TC27） | 5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/71/77/78; 4G: B1/2/3/4/5/7/8/13/17/20/28/38/39/40/41/42/43/66/71; 3G: 1/2/4/5/8; 2G: 850/900/1800/1900; Dual SIM/Dual Standby, VoLTE, Gigabit LTE-A, 5G NR Sub-6 (NSA, SA), LTE/NR Carrier Aggregation, supports private networking (LTE/5G) |
| WLAN Radio | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax; 2x2 MU-MIMO, Wi-Fi 6E (802.11ax), Wi-Fi™ certified; Wi-Fi™ 6 Certified, Dual Band Simultaneous; IPv4, IPv6 |
| WLAN 數據速率 | 6 GHz: 802.11ax—20 MHz, 40 MHz, 80 MHz, 160 MHz—up to 2402 Mbps 5 GHz: 802.11a/n/ac/ax—20 MHz, 40 MHz, 80 MHz, 160 MHz—up to 2402 Mbps; 2.4 GHz: 802.11b/g/n/ax—20 MHz up to 286.8 Mbps |
| 安全加密 | WEP (40 or 104 bit); Enhanced Open (OWE); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP256) - EAP-TLS; TC27 WWAN models only: WPA3 Enterprise EAP-SIM, EAP-AKA, EAP-AKA Prime |
| 認證 | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6; Wi-Fi Enhanced Open; WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Agile Multiband; WMM; WMM-Power Save; WMM Admission Control; Voice-Enterprise; Wi-Fi Direct; QoS Management; OCE |
| 快速漫遊 | PMKID caching; Cisco CCKM; 802.11r; OKC |
| WPAN（藍牙支持） | Class 2, Bluetooth v5.2 and Secondary BLE for beaconing within BLE battery |
